PURE POWER. TRUE VALUE.
The Freedom SW 2000 inverter/charger features pure sine wave output and power factor corrected multi-stage charging to meet power needs of today’s sensitive and sophisticated electronics. The Freedom SW 2000 offers premium performance and hard-to-match pricing in one package. It provides 2000 watts of continuous sine wave power to operate commonly used AC-powered electronics such as plasma television sets, microwaves, entertainment systems, computers, printers, power tools, mini refrigerator and much more. It packs a powerful 100 A charger and is available with an optional GFCI.
Application
Designed for a variety of mobile applications such as commercial, emergency and recreational vehicles,
marine vessels, construction and military equipment.
Product Features
Pure sine wave output to operate sensitive electronics
Built-in transfer switch automatically transfers between inverter power and incoming AC power
Power factor corrected multi-stage charger for fast, efficient charging
Temperature compensated charging for all climate conditions
Wide operating temperature range: 32°F to 122°F (0°C to 50°C)
Ignition lockout prevents unnecessary battery drain when the alternator is not providing power*
Adjustable low battery voltage cut-off
Conformal coated circuit boards for humid environments
On/off remote control panel with 25’ cable included (Part# 808-9002)
Easy to install and easy to use
Optional GFCI (part# 808-9003)
Meets CSA, UL458 (with marine supplement), ABYC and FCC Part 15, Class B requirements
*When used with On/off remote panel
Protection Features
Battery over-voltage and under-voltage protection
Over-temperature shutdown
Automatic overload protection
Short-circuit protection
Ground-fault protection on units with GFCI option
Also Available
FREEDOM SW 3000 Sine Wave Inverter/Charger (Part# 815-3000)
| Electrical Specifications - Inverter | |
|
Output power (continuous at 30°C) |
2000 W |
|
Surge rating (10 seconds) |
4000 W |
|
Output frequency |
60 Hz ± 0.2 Hz |
|
Output voltage |
120 Vac |
|
Output wave form |
Pure sine wave |
|
Optimal efficiency |
90% |
|
No-load power draw (inverting) |
2 Adc |
|
Input DC voltage range |
11 - 15 Vdc |
|
AC connections |
Single |
|
Low battery voltage cut-off |
10.5 V, 11.8 V (selectable) |
| Electrical Specifications - Charger | |||
|
Output current |
100 A |
||
|
Output voltage |
12 Vdc |
||
|
Output voltage range |
10.0 - 15.5 Vdc | ||
|
Charge control |
3 stage with manual equalize | ||
|
Charge temperature compensation |
Battery temperature sensor (included) | ||
|
Optimal Efficiency |
> 85% | ||
|
AC input power factor (full power) |
> 0.98 | ||
|
Input current (for 100/150 A charging) |
15.8 Aac | ||
|
Input AC voltage |
120 Vac | ||
|
Input AC voltage range |
95 - 140 Vac | ||
| Dead battery charge | > 8.5 Vdc | ||
| General Specifications | |
| Compatible battery types | Flooded / gel / AGM / |
| Transfer relay rating | 30 A, 120 Vac |
| Transfer time (AC to inverter and inverter to AC) | 20 ms |
| Optimal operating temperature range | - 4°F to 122°F (- 20°C to 50°C) |
| Storage ambient temperature range | - 4°F to 167°F (- 20°C to 75°C) |
| Optimal operating temperature range | 0°C to 50°C |
| Unit dimensions (H x W x L) | 7.75 x 13.5 x 15.25” (19.7 x 34.3 x 38.7 cm) |
| Unit weight | 27.5 kg (60.5 lbs) |
| Warranty | 2 years |
| Master carton quantity | 1 |
| Master carton dimensions | 11.8 x 17.1 x 20.5” (30 x 43.5 x 52.2 cm) |
| Master carton weight | 30 kg (66 lbs) |
| Part Number | 815-2000 |
| Accessories | |
| Freedom SW on/off remote panel | Part# 808-9002 - INCLUDED |
| Battery Temperature Sensor | Part# 808-0232-01 - INCLUDED |
| GFCI Option | Part# 808-9003 - SOLD SEPARATELY |
| Drip shield | Part# 808-9004 - SOLD SEPARATELY |
| Regulatory & Environmental Compliance | |
| ETL certified to CSA 107.1, UL458 with marine supplement**, FCC Class B | |
*When used with the Drip Shield. Drip Shield sold separately. Note: Specifications subject to change without notic
